Full-range Micro Motor Solutions
We specialize in hybrid stepper motors, BLDC motors and stepper drivers, producing 3 million units annually. Our products serve automated equipment in printers, ticket printers, engravers, medical instruments, stage lighting and textile machinery.
Inquire Now Contact Us| Driver Parameters | Min. | Rated | Max. | Unit |
| Input Voltage DC（V） | 80VAC | 220VAC | 240VAC | V |
| Output Current (A) | 1.29 | - | 8.2 Average5.86A | A |
| Input Pulse Frequency | 0 | - | 200K | Hz |
| Logic Input Current | 7 | 10 | 16 | MA |
| Insulation Resistance | 500 | - | - | MΩ |
| Cooling Method | Natural Cooling or Forced Cooling | |||
| Application Environment | Keep away from dust, oil contamination and corrosive gas | |||
| Operating Temperature | -20~+40℃ | |||
| Ambient Humidity | 40~90%RH(Non-condensing) | |||
| Storage Temperature | -20 ~+50℃ | |||
| Vibration | 5.9m/S2 max | |||
| Net Weight | 0.614 kg | |||
