Inquire Now Contact Us| 外壳材质 | Housing Material | Powder Metallurgy |
| 输出轴承形式 | Bearing at output | Powder Metallurgy |
| 径向负载 | Radial load (10mm from flange) | ≤20(N) |
| 轴向负载 | Shaft axial load | ≤10(N) |
| 静态主轴最大承受压入力 | Shaft press fit force max Static | ≤60(N) |
| 径向间隙 | Radial play of shaft | ≤0.08(mm) |
| 轴向间隙 | Thrust play of shaft | ≤0.3(mm) |
| 背隙（无负载时） | Backlash at no-load | ≤3° |
*负载与转速有关，具体数据需参考实际情况。
*Load relates to speed, actual value depends on different situation.
| Gear Ratio | Rated Permissible Load (Nm) | Intermittent Permissible Load (Nm) | Efficiency (%) | Length (mm) | Weight (g) | Reduction Stages |
|---|---|---|---|---|---|---|
| 1/4 | 0.1 | 0.3 | 90% | 23.5 | 45 | 1 |
| 1/6 | 0.1 | 0.3 | 90% | 23.5 | 45 | 1 |
| 1/24 | 0.4 | 1.2 | 80% | 29.2 | 55 | 2 |
| 1/144 | 0.8 | 2.5 | 72% | 34.7 | 65 | 3 |
| 1/576 | 1.0 | 3.0 | 65% | 43 | 80 | 4 |
