Inquire Now Contact Us| 外壳材质 | Housing Material | 粉末冶金 |
| 输出轴承形式 | Bearing at output | 滚珠轴承 |
| 径向负载 | Radial load (10mm from flange) | ≤450(N) |
| 轴向负载 | Shaft axial load | ≤200(N) |
| 静态主轴最大承受压入力 | Shaft press fit force max Static | ≤1000(N) |
| 径向间隙 | Radial play of shaft | ≤0.03(mm) |
| 轴向间隙 | Thrust play of shaft | ≤0.1(mm) |
| 背隙（无负载时） | Backlash at no-load | ≤1.5° |
*负载与转速有关，具体数据需参考实际情况。
*Load relates to speed, actual value depends on different situation.
| Reduction Ratio | Rated Permissible Load (Nm) | Intermittent Permissible Load (Nm) | Efficiency (%) | Length (mm) | Weight (g) | Reduction Stages |
|---|---|---|---|---|---|---|
| 1/4 | 2.0 | 6.0 | 81% | 41.3 | 491 | 1 |
| 1/6 | 2.0 | 6.0 | 81% | 41.3 | 491 | 1 |
| 1/15 | 8.0 | 25 | 72% | 59.6 | 700 | 2 |
| 1/18 | 8.0 | 25 | 72% | 59.6 | 700 | 2 |
| 1/26 | 16.0 | 50 | 72% | 59.6 | 700 | 2 |
| 1/47 | 16.0 | 50 | 72% | 59.6 | 700 | 2 |
| 1/66 | 16.0 | 50 | 72% | 59.6 | 700 | 2 |
