Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 700VAC 1 minute |
| 最大径向负荷 | Max Radial Force | 15N (10mm from front flange) |
| 最大轴向负荷 | Max Axial Force | 10N |
| Model | Poles | Phases | Rated Voltage(VDC) | Rated Speed(RPM) | Rated Torque(N.M) | Rated Current(Amps) | Output Power(Watts) | Peak Torque(N.M) | Peak Current(Amps) | Torque Constant(N.M/Amps) | Back EMF Constant(V/kRPM) | Moment of Inertia(g.c㎡) | Body Length(mm) | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 36BLX01 | 4 | 3 | 24 | 3000 | 0.02 | 0.40 | 6.0 | 0.06 | 1.2 | 0.054 | 5.7 | 23 | 40 | 0.15 |
| 36BLX02 | 4 | 3 | 24 | 3000 | 0.03 | 0.55 | 10 | 0.09 | 1.7 | 0.054 | 5.7 | 34 | 50 | 0.21 |
| 36BLX03 | 4 | 3 | 24 | 3000 | 0.04 | 0.80 | 13 | 0.12 | 2.4 | 0.054 | 5.7 | 45 | 57 | 0.27 |
| 36BLX04 | 4 | 3 | 24 | 3000 | 0.01 | 0.20 | 3.0 | 0.03 | 0.6 | 0.054 | 5.7 | 14 | 26 | 0.09 |
