We specialize in hybrid stepper motors, BLDC motors and stepper drivers, producing 3 million units annually. Our products serve automated equipment in printers, ticket printers, engravers, medical instruments, stage lighting and textile machinery.
Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 600VAC 1 minute |
| MODEL | Poles | PhasesRated Voltage (RPM) | Rated Torque(N.M) | Rated Current(Amps) | Output Power(Watts) | Peak Torque(N.M) | Peak Current(Amps) | Torque Constant(N.M/Amps) | Back EMF Constant(V/kRPM) | Moment of Inertia(g.c㎡) | Body Length(mm) | Weight (kg) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 24BLX01 | 4 | 3 | 24 | 3000 | 0.014 | 0.3 | 4 | 0.042 | 0.9 | 0.044 | 4.6 | 2.6 | 30 | 0.065 |
*The above are representative products; derivative products can be customized according to customer requirements.
*This product is compatible with 36and 42gear reducers.
