Inquire Now Contact UsHTD856 ultra-quiet high-torque two-phase digital stepper motor driver, compatible with 57/60/86 series stepper motors. Equipped with 32-bit ARM Cortex-M4 processor, max output current 7.2A, max input voltage 80VDC. Supports up to 2MHz pulse frequency and 25600 microsteps. Built-in self-test, dual working modes, 5–24V signal input.
Electrical Specifications
| Driver Parameters | Min. | Rated | Max. |
|---|---|---|---|
| Input Voltage DC(V) | 18 | 48 | 75 |
| Drive Current(A) | 2.0 | 5.6 | |
| Input Pulse Frequency(Hz) | 1 | 1M | |
| Input Pulse Width(ns) | 250 | 5E+8 | |
| Input Signal Voltage(VDC) | 3.6 | 5 | 24 |
Environmental Specifications
| Environmental Factors | Environmental Specifications |
|---|---|
| Cooling Method | Natural Cooling or Forced Cooling |
| Application Environment | Keep away from dust, oil contamination and corrosive gas |
| Operating Temperature | 0°C--40°C |
| Ambient Humidity | 90%RH |
| Storage Temperature | -10°C--70°C |
