Full-range Micro Motor Solutions
We specialize in hybrid stepper motors, BLDC motors and stepper drivers, producing 3 million units annually. Our products serve automated equipment in printers, ticket printers, engravers, medical instruments, stage lighting and textile machinery.
Inquire Now Contact Us| Driver Parameters | Min. | Rated | Max. | Unit |
| Input Voltage DC（V） | 18 | 48 | 50 | DVC |
| Drive Current（A） | 1.0 | - | 2.5 | A |
| Input Pulse Frequency | 1 | - | 200K | Hz |
| Input Pulse Width | 250 | - | 5E+8 | ns |
| IR | 500 | - | - | MΩ |
| Cooling Method | Natural Cooling or Forced Cooling | |||
| Application Environment | Keep away from dust, oil contamination and corrosive gas | |||
| Operating Temperature | 0~40℃ | |||
| Ambient Humidity | 90%RH(Non-condensing) | |||
| Storage Temperature | -10 ~70℃ | |||
| Vibration | 5.9m/S2 max | |||
| Net Wt. | 0.273 kg | |||
