Inquire Now Contact UsElectrical Specifications
| Driver Parameters | Min. | Rated | Max. | Unit |
|---|---|---|---|---|
| Input Voltage DC | 12 | 24 | 50 | VDC |
| Drive Current | 0.3 | 2.5 | A | |
| Input Pulse Frequency | 1 | 1M | Hz | |
| Input Pulse Width(ns) | 250 | 5E+8 | ns | |
| Input Signal Voltage(VDC) | 3.6 | 5 | 24 | VDC |
Environmental Specifications
| Environmental Factors | Environmental Specifications |
|---|---|
| Cooling Method | Natural Cooling or Forced Cooling |
| Application Environment | Keep away from dust, oil contamination and corrosive gas |
| Operating Temperature | 0°C--40°C |
| Ambient Humidity | 90%RH (Non-condensing) |
| Storage Temperature | -10°C--70°C |
| Vibration | 5.9m/S㎡max |
