Inquire Now Contact UsHTD522 is an ultra-quiet, high-torque two-phase digital stepper motor driver. Compatible with 28/35/39/42/57 series two-phase stepper motors, max output current 2.5A. Powered by 32-bit ARM Cortex-M4 processor, it supports up to 2MHz pulse input and 25600 microsteps. Features self-test function, switchable signal modes, and 5–24V signal input.
Electrical Specifications
| Driver Parameters | Min. | Rated | Max. |
|---|---|---|---|
| Input Voltage DC DC(V) | 12 | 24 | 60 |
| Drive Current(A) | 0.3 | 2.5 | |
| Input Pulse Frequency(Hz) | 1 | 1M | |
| Input Pulse Width(ns) | 250 | 5E+8 | |
| Input Signal Voltage(VDC) | 3.6 | 5 | 24 |
Environmental Specifications
| Environmental Factors | Environmental Specifications |
|---|---|
| Cooling Method | Natural Cooling or Forced Cooling |
| Application Environment | Keep away from dust, oil contamination and corrosive gas |
| Operating Temperature | 0°C--40°C |
| Ambient Humidity | 90%RH |
| Storage Temperature | -10°C--70°C |
