Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 500VAC 1 minute |
| Model | Gear Ratio | Gearbox Diameter | Number of Poles | Number of Phases | Rated Voltage(VDC) | Rated Torque (N.M) | Rated Speed (RPM) | Rated Current(Amps) | Output Power (Watts) | Gearbox Height(mm) | Motor Height(mm) | Total Weight(KG) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 57BLF01-019AG6 | 1/6 | 56 | 8 | 3 | 24 | 0.97 | 500 | 3.7 | 50 | 41.3 | 59 | 1.11 |
| 57BLF02-045AG6 | 1/6 | 56 | 8 | 3 | 24 | 1.97 | 500 | 7.0 | 103 | 41.3 | 80 | 1.44 |
| 57BLF03-049AG15 | 1/15 | 56 | 8 | 3 | 24 | 6.50 | 200 | 10.2 | 136 | 59.6 | 101 | 1.95 |
| 56mm Planetary Gearbox | |||
|---|---|---|---|
| Gear Ratio | Intermittent Permissible Load (Nm) | Length (mm) | Reduction Stages |
| 1/4 | 6.0 | 41.3 | 1 |
| 1/6 | |||
| 1/15 | 25 | 59.6 | 2 |
| 1/18 | |||
| 1/26 | 50 | 59.6 | 2 |
| 1/47 | |||
| 1/66 | |||
| 56mm Zinc Alloy Planetary Gearbox | |||
| Gear Ratio | Intermittent Permissible Load (Nm) | Length (mm) | Reduction Stages |
| 1/13 | 6.0 | 52.7 | 1 |
| 56mm Alternative Planetary Gearbox Models | |||
| Gear Ratio | Intermittent Permissible Load (Nm) | Length (mm) | Reduction Stages |
| 1/4 | 6.0 | 43.3 | 1 |
| 1/6 | |||
| 56mm Zinc Alloy & Engineering Plastic Planetary | |||
| Gear Ratio | Intermittent Permissible Load (Nm) | Length (mm) | Reduction Stages |
| 1/15 | 25 | 61.6 | 2 |
| 1/18 | |||
| 1/26 | |||
| 1/47 | 50 | 61.6 | 2 |
| 1/66 | |||
