Full-range Micro Motor Solutions
We specialize in hybrid stepper motors, BLDC motors and stepper drivers, producing 3 million units annually. Our products serve automated equipment in printers, ticket printers, engravers, medical instruments, stage lighting and textile machinery.
Inquire Now Contact Us| 绝缘等级 | Insulation Class | F |
| 防护等级 | Protection Level | IP65 |
| 环境要求 | Environment Requirement | 工作/Work: 0℃~+55℃ 保存/Preserve： 20℃～80℃ 工作或保存/Work or Preserve: 90%RH （无结露/No Condensation) 海拔1000米/ Above Sea Level 1000m 振动/ Vibration： 5.88/S 2.10-60Hz |
| Model | Rated Power(Watts) | Rated Voltage | Rated Current(Amps) | Rated speed(RPM) | Rated Torque (N.M) | Peak Torque (N.M) | Back EMF (V/kRPM) | Torque Constant(N.M/Amps) | Moment of Inertia g·cm² 1000 1250 1500(Kg.cm2) | Winding Resistance (Between Lines)(Ω) | Winding Inductance (Between Lines)(mH) | Electrical Time Constant(Ms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ES4004A-10D30A1 | 100 | 310 | 1.2 | 3000 | 0.32 | 0.96 | 16 | 0.265 | 0.045 | 11 | 8 | 0.86 |
| ES4004A-10D30N1 | 100 | 310 | 1.2 | 3000 | 0.32 | 0.96 | 16 | 0.265 | 0.045 | 11 | 8 | 0.86 |
| ES4004A-10D30A2 | 100 | 310 | 1.2 | 3000 | 0.32 | 0.96 | 16 | 0.265 | 0.045 | 11 | 8 | 0.86 |
| ES4004A-10D30N2-001 | 100 | 310 | 1.2 | 3000 | 0.32 | 0.96 | 16 | 0.265 | 0.045 | 11 | 8 | 0.86 |
| ES4004A-10D30L1 | 100 | 310 | 1.2 | 3000 | 0.32 | 0.96 | 16 | 0.265 | 0.045 | 11 | 8 | 0.86 |
| ES4004A-10D30L2 | 100 | 310 | 1.2 | 3000 | 0.32 | 0.96 | 16 | 0.265 | 0.045 | 11 | 8 | 0.86 |
| ES4005A-05S30N1-001 | 50 | 310 | 0.56 | 3000 | 0.16 | 0.48 | 16 | 0.265 | 0.03 | 23 | 16 | 0.86 |
| ES4005A-05S30N2-001 | 50 | 310 | 0.56 | 3000 | 0.16 | 0.48 | 16 | 0.265 | 0.03 | 23 | 16 | 0.86 |
| Low Voltage ServoES40004K-10D30L3 | 100 | 24 | 5.6 | 3000 | 0.32 | 0.9 | 6 | 0.057 | 0.045 | 0.6 | 0.86 | 1.08 |
