Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 1500VAC 1 minute |
| 最大径向负荷 | Max Radial Force | 330N (10mm from front flange) |
| 最大轴向负荷 | Max Axial Force | 100N |
| Model | Number of Poles | Number of Phases | Rated Voltage(VDC) | Rated Torque (N.M) | Rated speed(RPM) | Rated Current(Amps) | Output Power (Watts) | Peak Torque(N.M) | Peak Current (Amps) | Torqueconstant (N.M/Amps) | Back EMF(V/kRPM) | Body Length(mm) | Mass(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 110BLF01 | 8 | 3 | 310 | 3.5 | 3000 | 4.72 | 1100 | 10.5 | 14.0 | 0.74 | 77.5 | 156.0 | 5.08 |
| 110BLF02 | 8 | 3 | 310 | 4.5 | 3000 | 6.10 | 1413 | 13.5 | 18.3 | 0.74 | 77.5 | 177.0 | 6.06 |
| 110BLF03 | 8 | 3 | 310 | 6.5 | 3000 | 8.77 | 2040 | 19.5 | 26.3 | 0.74 | 77.5 | 216.0 | 7.88 |
*The above are representative products; derivative products can be customized according to customer requirements.
