Inquire Now Contact Us| Winding Type | Star |
| Hall Effect angle | 120° electrical angle |
| Insulation Class | B |
| Ambient Temperature Range | -20℃~+50℃ |
| Insulation Resistance | 100MΩ Min.500V DC |
| Dielectric Strength | 750VAC 1minute |
| Model 电机型号 | 单位 | 90BLY01A | 90BLY02A | 90BLY03A |
|---|---|---|---|---|
| Number of Poles 极数 | - | 3 | 3 | 3 |
| Number of Phases 相数 | - | 8 | 8 | 8 |
| Rated Voltage 额定电压 | VDC | 310 | 310 | 310 |
| Rated speed 额定转速 | RPM | 2800 | 3500 | 3500 |
| Rated Torque 额定力矩 | N-m | 0.22 | 0.5 | 0.7 |
| Rated Current 额定电流 | Amps | 0.4 | 0.73 | 1.2 |
| Output Power 输出功率 | Watts | 65 | 183 | 256 |
| Peak Torque 峰值力矩 | N-m | 0.66 | 1.5 | 3.6 |
| Peak Current 峰值电流 | Amps | 1.2 | 2.2 | 7.8 |
| Torqueconstant 力矩常数 | N-m/Amps | 0.56 | 0.69 | 0.69 |
| Back EMF 反电势常数 | V/kRPM | 58.5 | 72 | 72 |
| Rotor inertia 转动惯量 | g·cm² | 1000 | 1250 | 1500 |
| Body Length (L) 机身长度 | mm | 78.5 | 75 | 91 |
| Mass 重量 | kg | 1.2 | 1.75 | 2.3 |
Caution 1: Peak Torque is provided for the purpose of performance calculations only. Operate near, or at this condition will result in motor damaged. 峰值力矩仅作为参数参考，接近或在此条件下长时间使用，将导致电机损坏Note: We can also manufacture products according to customer's requirements. 以上仅为代表产品，派生产品可根据客户要求制作。
