Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 600VAC 1 minute |
| 最大径向负荷 | Max Radial Force | 28N (10mm from front flange) |
| 最大轴向负荷 | Max Axial Force | 10N |
| Model | Poles | Phases | Rated Voltage(VDC) | Rated Torque(N.M) | Rated Speed(RPM) | Rated Current(Amps) | Output Power(Watts) | Peak Torque(N.M) | Peak Current(Amps) | Torque Constant(N.M/Amps) | Back EMF Constant(V/kRPM) | Body Length(mm) | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 42BLFX01 | 8 | 3 | 48 | 0.13 | 4400 | 2.0 | 60 | 0.39 | 6.0 | 0.064 | 6.7 | 59.2 | 0.39 |
| 42BLFX02 | 8 | 3 | 48 | 0.22 | 4600 | 3.5 | 106 | 0.66 | 10.5 | 0.063 | 7.1 | 84.2 | 0.59 |
*The above are representative products; derivative products can be customized according to customer requirements.
*This product is compatible with 36,42,56 gear reducers.
