Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 600VAC 1 minute |
| Model | Gear Ratio | Gearbox Diameter | Number of Poles | Number of Phases | Rated Voltage (VDC) | Rated Torque(N.M) | Rated Speed(RPM) | Rated Current (Amps) | Output Power (Watts) | Gearbox Height(mm) | Motor Height(mm) | Total Weight(KG) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 36BLY01A-001AG76 | 1/76 | 36 | 4 | 3 | 24 | 1.5 | 94 | 2.5 | 15 | 41.9 | 42.1 | 0.40 |
| 36mm Planetary Gearbox | |||
|---|---|---|---|
| Gear Ratio | Intermittent Permissible Load（Nm） | Length (mm) | Reduction Stages |
| 1/4 | 1.0 | 24.8 | 1 |
| 1/5 | |||
| 1/16 | 3.5 | 32.4 | 2 |
| 1/20 | |||
| 1/25 | |||
| 1/53 | 7.5 | 41.9 | 3 |
| 1/62 | |||
| 1/76 | |||
| 1/94 | |||
| 1/117 | |||
| 36mm Split Type Planetary Gearbox | |||
| Gear Ratio | Intermittent Permissible Load（Nm） | Length (mm) | Reduction Stages |
| 1/3.7 | 4 | 28 | 1 |
| 1/5.18 | |||
| 1/13.76 | 5 | 35.5 | 2 |
| 1/19.22 | |||
| 1/26.83 | |||
| 1/51 | 6 | 43 | 3 |
| 1/71.3 | |||
| 1/100 | |||
| 1/139 | |||
| 36mm Zinc Alloy Planetary Gearbox | |||
| Gear Ratio | Intermittent Permissible Load (Nm) | Length (mm) | Reduction Stages |
| 1/12 | 1.0 | 26.8 | 1 |
