Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 500VAC 1 minute |
| Model | Gear Ratio | Gearbox Diameter | Number of Poles | Number of Phases | Rated Voltage (VDC) | Rated Torque (N.M) | Rated Speed (RPM) | Rated Current (Amps) | Output Power (Watts) | Gearbox Height(mm) | Motor Height(mm) | Total Weight(KG) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 28BL01AG14 | 1/14 | 28 | 4 | 3 | 12 | 0.15 | 214 | 0.9 | 3.4 | 29.8 | 40.5 | 0.25 |
| 28BL02AG30 | 1/30 | 28 | 4 | 3 | 24 | 0.65 | 100 | 1.0 | 6.8 | 29.8 | 53 | 0.31 |
| 28BL03AG64 | 1/64 | 28 | 4 | 3 | 24 | 2.00 | 46 | 2.0 | 9.6 | 40 | 78 | 0.36 |
| 28mm Square Planetary Gearbox | |||
|---|---|---|---|
| Gear Ratio | Intermittent Permissible Load (Nm) | Length (mm) | Reduction Stages |
| 1/3 | 0.6 | 28.5 | 1 |
| 1/6 | |||
| 28mm Round Planetary Gearbox | |||
| Gear Ratio | Intermittent Permissible Load (Nm) | Length (mm) | Reduction Stages |
| 1/14 | 1.5 | 29.8 | 1 |
| 1/30 | |||
| 1/64 | 5 | 40.0 | 1 |
| 1/107 | |||
