Inquire Now Contact Us| 绝缘等级 | Insulation Class | F |
| 防护等级 | Protection Level | IP65 |
| 环境要求 | Environment Requirement | 工作/Work: 0℃~+55℃ 保存/Preserve： 20℃～80℃ 工作或保存/Work or Preserve: 90%RH （无结露/No Condensation) 海拔1000米/ Above Sea Level 1000m 振动/ Vibration： 5.88/S 2.10-60Hz |
| Model | Rated Power(Watts) | Rated Voltage | Rated Current (Amps) | Rated Speed(RPM) | Rated Torque(N.M) | Peak Torque (N.M) | Back EMF (V/kRPM) | Torque Constant(N.M/Amps) | Moment of Inertia (Kg.cm2) | Winding Resistance (Between Lines)(Ω) | Winding Inductance (Between Lines)(mH) | Electrical Time Constant(Ms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ES13005A-100D20L1 | 1000 | 310 | 5.5 | 2000 | 4.70 | 14.70 | 55 | 0.6 | 4.5 | 1.20 | 12.0 | |
| ES13005A-100D20L2 | 1000 | 310 | 5.5 | 2000 | 4.70 | 14.70 | 55 | 0.6 | 4.5 | 1.20 | 12.0 | |
| ES13005A-150D20L1 | 1500 | 310 | 8.8 | 2000 | 7.2 | 21.60 | 62 | 0.6 | 6.7 | 0.80 | 8.4 | |
| ES13005A-150D20L2 | 1500 | 310 | 8.8 | 2000 | 7.2 | 21.60 | 62 | 0.6 | 6.7 | 0.80 | 8.4 | |
| ES13005A-200D20L1 | 2000 | 310 | 12.0 | 2000 | 9.55 | 28.65 | 80 | 0.79 | 8.9 | 0.50 | 5.4 | |
| ES13005A-200D20L2 | 2000 | 310 | 12.0 | 2000 | 9.55 | 28.65 | 55 | 0.6 | 8.9 | 0.46 | 6.5 | |
| ES13005A-400D10L1 | 2000 | 310 | 9.5 | 1000 | 20.0 | 40.0 | 153 | 1.5 | 17.8 | 1.10 | 13.7 | |
| ES13005A-400D10L2 | 2000 | 310 | 9.5 | 1000 | 20.0 | 40.0 | 153 | 1.5 | 17.8 | 1.10 | 13.7 |
