Inquire Now Contact Us| 绝缘等级 | Insulation Class | F |
| 防护等级 | Protection Level | IP65 |
| 环境要求 | Environment Requirement | 工作/Work: 0℃~+55℃ 保存/Preserve： 20℃～80℃ 工作或保存/Work or Preserve: 90%RH （无结露/No Condensation) 海拔1000米/ Above Sea Level 1000m 振动/ Vibration： 5.88/S 2.10-60Hz |
| Model | Rated Power (Watts) | Rated Voltage | Rated Current (Amps) | Rated Speed (RPM) | Rated Torque (N.M) | Peak Torque (N.M) | Back EMF (V/kRPM) | Torque Constant(N.M/Amps) | Moment of Inertia (Kg.cm2) | Winding Resistance (Between Lines) (Ω) | Winding Inductance (Between Lines)(mH) | Electrical Time Constant(Ms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ES8004A-75S30B1 | 750 | 310 | 4.0 | 3000 | 2.4 | 7.2 | 39 | 0.6 | 1.51 | 1.4 | 9.0 | |
| ES8005A-75D30A1 | 750 | 310 | 4.0 | 3000 | 2.4 | 7.2 | 39 | 0.6 | 1.51 | 1.5 | 11.0 | |
| ES8005A-75D30B2 | 750 | 310 | 4.0 | 3000 | 2.4 | 7.2 | 39 | 0.6 | 1.51 | 1.5 | 11.0 | |
| ES8005A-75D30L1 | 750 | 310 | 4.0 | 3000 | 2.4 | 7.2 | 39 | 0.6 | 1.51 | 1.5 | 11.0 | |
| ES8005A-75D30L2 | 750 | 310 | 4.0 | 3000 | 2.4 | 7.2 | 39 | 0.6 | 1.51 | 1.5 | 11.0 | |
| 低压伺服 ES8004G-75S30B1 | 750 | 48 | 20 | 3000 | 2.38 | 7.2 | 8 | 0.132 | 1.51 | 0.15 | 0.5 |
