Full-range Micro Motor Solutions
We specialize in hybrid stepper motors, BLDC motors and stepper drivers, producing 3 million units annually. Our products serve automated equipment in printers, ticket printers, engravers, medical instruments, stage lighting and textile machinery.
Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 600VAC 1 minute |
| 最大径向负荷 | Max Radial Force | 220N(10mm from front flange) |
| 最大轴向负荷 | Max Axial Force | 60N |
| Model | Poles | Phases | Rated Voltage(VDC) | Rated Torque(N.M) | Rated Speed(RPM) | Rated Current(Amps) | Output Power(Watts) | Peak Torque(N.M) | Peak Current(Amps) | Torque Constant(N.M/Amps) | Back EMF Constant(V/kRPM) | Body Length(mm) | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 80BL01A | 4 | 3 | 48 | 0.7 | 3000 | 6.36 | 220 | 2.1 | 19.0 | 0.11 | 12 | 105.0 | 2.19 |
| 80BL02A | 4 | 3 | 48 | 1.2 | 3000 | 11.0 | 376 | 3.6 | 33.0 | 0.11 | 12 | 132.5 | 2.80 |
| 80BL03A | 4 | 3 | 310 | 1.8 | 3000 | 2.43 | 565 | 5.4 | 7.3 | 0.74 | 77.5 | 160.0 | 3.50 |
The above are representative products; derivative products can be customized according to customer requirements.
