Inquire Now Contact Us| 绕线接法 | Winding Type | Star |
| 霍尔角度 | Hall effect angle | 120° Electrical angle |
| 绝缘等级 | Insulation Class | B |
| 环境温度 | Ambient Temperature | -20℃~+50℃ |
| 绝缘电阻 | Insulation Resistance | 100MΩ Min.500 VDC |
| 绝缘强度 | Dielectric Strength | 600VAC 1 minute |
| Model | Poles | Phases | Rated Voltage(VDC) | Rated Speed(RPM) | Rated Torque(N.M) | Rated Current(Amps) | Output Power(Watts) | Peak Torque(N.M) | Peak Current(Amps) | Torque Constant(N.M/Amps) | Back EMF Constant(V/kRPM) | Moment of Inertia(g.c㎡) | Body Length(mm) | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 75BLX01 | 8 | 3 | 40 | 3500 | 0.64 | 7.40 | 235 | 1.9 | 22.2 | 0.093 | 9.70 | 648 | 110 | 2.0 |
| 75BLX02 | 8 | 3 | 40 | 3100 | 1.10 | 10.5 | 357 | 3.3 | 31.5 | 0.104 | 10.9 | 813 | 140 | 2.5 |
| 75BLX03 | 8 | 3 | 40 | 3100 | 1.47 | 12.0 | 477 | 4.4 | 36.0 | 0.104 | 10.9 | 980 | 165 | 3.0 |
*The above are typical products. Derivatives can be customized to meet customer demands.
*This unit may be fitted with a 75 gear reducer.
